Tool measurement on the machine
TT 160 S01 3YS08 FA 0.00 .. SC02 HTL
| Ident number | 729763-02 |
|---|---|
| Fastening type | Fixing clamp fastening |
| Geometry of the stylus | Ø 25 mm probe contact |
| Degree of protection | IP68 (EN60529) |
| Power supply | 10V...30V |
| Output signal | Square-wave signals, HTL levels |
| Operating temperature | +10/+40 °C |
| Cable type | w/o cable |
| Electrical connection | Flange socket M12, male, 8-pin |
